嵌入式电脑系统
TERA - 2I640DW
Compact Fanless Embedded Computer
with Elkhart Lake ATOM® x6413E
/ J6412 Processor
with Elkhart Lake ATOM® x6413E
/ J6412 Processor
概览
TERA 2I640DW 是一款紧凑型无风扇嵌入式计算机，尺寸为 56.5 x 102.4 x 145 毫米。它采用 Intel Elkhart Lake Atom® 处理器，专为空间受限的应用而设计，例如工厂数据收集、AIot、边缘计算和网关。
TERA 2I640DW 配备多个 I/O，例如 2 个 HDMI、3 个 2.5 GbE网口、2 个 USB 3.0 端口、2 个 USB 2.0 端口和2 个 COM 端口以及可选的隔离数字 I/O，用于工业通信和控制。此外，通过采用M.2 插槽，TERA 2I640DW可以充分利用WiFi 6、4G/5G无线通信的带宽，为AIoT和边缘网关应用提供广域覆盖和实时数据传输。
低功耗和轻量化机械设计的属性也使 TERA 2I640DW成为受限空间受限边缘计算应用的项目如智能机器人控制、智能交通、智能医疗、视觉检测和分析的理想解决方案。
特点
- Elkhart Lake ATOM® x6413E / J6412 CPU
- 1 x DDR4 SODIMM socket, Max. 32GB
- Multiple Independent display: 2 x HDMI (OEM Option to DP)
- 3 x Intel 2.5 GbE LAN, 2 x USB 3.0, 2 x USB 2.0, 2 x COM
- 2 x M.2, 4DI / 4DO (option), 1 x Nano SIM
| MODEL | TERA-2I640DW | |
|---|---|---|
| System Dimension(WxDxH) | 145W x 102.4D x 56.5H mm | |
| Weight(Incl.M/B) | 0.88 kg | |
| CPU | Intel® Elkhart Lake ATOM x6413E Quad Core 3.0 GHz CPU Intel® Elkhart Lake Celeron J6412 Quad Core 2.6 GHz CPU |
|
| Chipset | Intel Elkhart Lake SoC | |
| Memory | 1 x DDR4 SODIMM socket, Max. 32GB | |
| Expansion slots | 1 x M.2 B Key Type 2242 / 3042 (PCIe x2 / USB 3.0 / USB 2.0) 1 x M.2 B Key Type 2242 (PCIe x2 / USB 2.0 / SATA) 1 x Nano SIM |
|
| I/O ports | Network | 3 x Intel 2.5 GbE I225 (external) |
| USB | 2 x USB 3.0, 2 x USB 2.0 | |
| Serial ports | 2 x RS232 / 422 / 485 | |
| Display | 2 x HDMI (OEM Option to DP) | |
| DI/O | 4DI / 4DO (option) | |
| Optional Modules & Accessory |
GPS, Bluetooth, PoE, WiFi, 4G LTE, Isolated COM, battery UPS, DI / DO, Video Input *VESA / Wall Mounting Kit, DIN Rail Mounting Kit |
|
| Power | DC input : Wide Range +9~24V AC input : External adapter 100 / 240V (optional) |
|
| Operating Temp. (100 % CPU usage) |
-20°C to +60°C (X6413E) ; -40°C by OEM Option, 0°C to +60°C (J6412) *With wide range temperature memory & storage |
|
| Storage Temp. | -40°C to +70°C | |
| Relative Humidity | 95% @ 40°C, non-condensing | |
| OS Support | Windows® 10 IOT, Windows® 11 IOT Ubuntu 22.04 above, Fedora 36 above |
|
