| LEX Pico-ITX SBC 2I390CW with |
| Flexible Expansions utilizing Intel® Apollo Lake SoC Processor |
| LEX Computech released of the next generation Pico-ITX SBC with optional LEX eIO (2 x PCIe + USB) expansion function: 2I390CW is based on the latest Intel® Apollo Lake processor, integrated 2 x GbE LAN, 5 x USB, 2 x COM Port and HDMI, DVI display interface that offer the ideal platforms for high performance applications in Digital Signage, medical devices, POS/Kiosk, gaming machines, automation, military & industrial facilities. |
|
| |
| |
2I390CW |
Compact solution with Rich Expansion for vertical application |
| • Intel® Apollo Lake N4200 / N3350 / E3950 SoC CPU / chipset |
| • On board DDR3L 4GB |
| • Display: eDP, HDMI & DVI |
| • 2 x GbE, 2 x Mini PCIe, 2 x USB 3.0, 3 x USB 2.0 |
| • 4DI/4DO, HD audio, 2 x COM, Lex eIO: 2 x PCIe + USB |
| • Wide Range DC IN +9~36V |
| • Wide temperature support of -40°C ~ 70°C |
| • Support 4K UHD resolution content |
|
 |
|
|
| Rich Expansion for Vertical Application |
| |
2I390CW adds one full-size Mini PCIe slot & one half-size Mini PCIe slot.
One Mini PCIe slot with PCIe, mSATA and USB interfaces and another with
mSATA and USB interfaces. They can be used to expand more I/O connectivity
like 4-port serial, Video capture card, SIM card socket, and USB 3.0 by mini PCIe
modules. Also wireless WiFi, Bluetooth, and GPS Mini PCIe module expansion
possibilities. More I/O interfaces can be supported from eIO modules such as
L2L001 & L2L002. |
|
| |
|
| |
|
| • 5 PCIe Giga LAN |
| • Intel I210-IT / I211-AT |
| • 1 Mini PCI Express socket. |
| • USB and PCIe (Option, share fifth LAN port) |
| • SIM-Push-Push |
|
|
|
| |
|
| L2L002 |
| • 4 PCIe Giga LAN |
| • Intel I210-IT/I211-AT |
| • 1 port 1000Base-SX fiber. |
| • 1 Mini PCI Express socket. |
| • USB and PCIe (Option, share fiber LAN port) |
| • SIM-Push-Push |
|
|
| |
| L2M001 |
| • 4 Mini PCI Express socket (full size) |
| • Support USB and PCIe, SIM-Push-Push |
| • For option : USB3.0 x 2 |
|
|
|
| |
|
| |
|
| |
| Dimension: 56.5H x 145W x 106.2D mm |
| • Compact heat-dissipating System |
| • Robust & Powerful Fanless Embedded solution |
|
|
|
| |
|
| 2I390CW + 2 x L2L002 |
| 2I390CW + L2L001 |
|
|
| Dimension: 63 H x 150 W x 80.8 D mm (1 x eIO Card) |
| 85 H x 150 W x 80.8 D mm (2 x eIO Card) |
| • Compact heat-dissipating System |
| • Robust & Powerful Fanless Embedded solution |
|
|
|
|
| |
| 2I390CW + 2 x L2L001 |
2I390CW + L2L001 |
|
|
|
| Dimension: 72 H x 140 W x 92 D mm (1 x eIO Card) |
| 93.6 H x 140 W x 92 D mm (2 x eIO Card) |
| • Industrial networking solution |
| • Powerful Fanless Din-Rail solution |
|
|
|
|
|
|
