| Maximizing performance 3.5” Single Board Computers with |
| Intel® Apollo Lake SoC Processor |
| LEX Computech released of the next generation 3.5” motherboard with wide range 9~36V DC power input: 3I390AW is based on the latest Intel® Apollo Lake processor, integrated 2 x GbE LAN, 6 x USB, 6 x COM Port and VGA, DVI display interface that offer the ideal platforms for high performance applications in Digital Signage, medical devices, POS/Kiosk, gaming machines, automation, military & industrial facilities. |
|
| |
| |
3I390AW |
Completed solution for IoT & Industry 4.0 |
| • Intel® Apollo Lake N4200 / N3350 / E3950 SoC CPU / chipset |
| • 1 x DDR3L SODIMM socket, max. Upto 8GB |
| • Display Interface: VGA & DVI |
| • 2 x Intel GbE, 2 x Mini PCIe, 1 x SIM |
| • 6 x USB (4 x USB 3.0 + 2 x USB 2.0), HD Audio, 6 x COM |
| • Wide Range DC IN +9~36V |
| • Wide temperature support of -40°C ~ 70°C |
| • Support 4K UHD resolution content |
 |
|
| |
|
| |
|
| Dimension: 77H x 210W x 125D mm |
| • Super Excellent heat-dissipating System |
| • Robust & Powerful Fanless Embedded solution |
|
|
|
| |
|
|
