IP66/IP67 Box PC
SHARK 10.1" Box PC + 2I610HW
10.1" IP67 Waterproof Fanless Embedded Computer
with Intel® 6th / 7th Gen Intel® Skylake /
Kaby Lake-U, i7 / i5 / i3 / Celeron CPU
with Intel® 6th / 7th Gen Intel® Skylake /
Kaby Lake-U, i7 / i5 / i3 / Celeron CPU
Features
- Intel® Skylake / Kaby Lake-U, i7 / i5 / i3 / Celeron CPU
- 1 x DDR4 1866 / 2133 MHz SODIMM, Max. 32GB
- M12 IO connectors
- Aluminum housing
SHARK 10.1" Box PC + 2I610HW Datasheet
SHARK 10.1" Box PC + 2I610HW CE
SHARK 10.1" Box PC + 2I610HW FCC
SHARK 10.1" Box PC + 2I610HW LVD
| MODEL | SHARK 10.1" Box PC + 2I610HW | |
|---|---|---|
| Dimension (mm) | 249.56W x 168.2D x 40H mm | |
| Weight | 2 kg | |
| CPU | Intel® Skylake / Kaby Lake-U, i7 / i5 / i3 / Celeron CPU | |
| Chipset | Intel Skylake / Kaby Lake-U SoC | |
| Memory | 1 x DDR4 SODIMM, Max. 32GB | |
| Storage | mSATA, HDD / SSD* | |
| Expansion slots | 1 x Full-size Mini PCIe (PCIe / USB / mSATA) 1 x Full-size Mini PCIe (PCIe / USB) |
|
| M12 I /O ports (Selectable) | Network | 2 x Intel GbE |
| USB | 4 x USB 2.0, 2 x USB 3.0 | |
| Serial ports | 4 x RS232 / 422 / 485 | |
| Display | 1 x VGA, HDMI | |
| Optional Modules & Function |
GPS, Bluetooth, PoE, WiFi, 4G LTE, Isolated COM, battery UPS *SATA Kit, *VESA Mount Kit, *External power adapter |
|
| Power | DC input : +9~36V AC input : External adapter 100 / 240V, AC-DC (optional) |
|
| Operating Temp. (100 % CPU usage) |
-20°C to +50°C with mSATA / SSD | |
| Storage Temp. | -20°C to +70°C | |
| Relative Humidity | 95% @ 40°C, non-condensing | |
| IP Rating | IP66 / IP67 Compliant | |
| OS Support |
7th Generation Intel® Core™ Processor family: Kaby Lake Windows® 10 IOT (64bit), 6th Generation Intel® Core™ Processor family: Skylake Windows® 10 IOT (64bit), Windows® 8.1 (64bit), Windows® Embedded 8 Standard (64bit), |
|
