HAWK - 3I130TW
13th Gen Intel® Raptor Lake-U Processor
Overview
LEX System Fanless Embedded System: HAWK 3I130TW is based on Intel® 13th Raptor Lake-U Core i processor, integrated 5 x 2.5 GbE, 4 x USB , 2 x ISO-COM or ISO-CANBus , HD Audio, DI/DO, DP, HDMI and Type C DP ALT mode display interface; plus with 3 x M.2 , 1 x Nano SIM expansion and ISO wide range 9~+36V DC input (optional to 18-75V/ SIP 20~53V),1.6KVDC I/O isolation and Power ignition delay on/off control which could protect computing systems from damage causing by unexpected voltage and current and makes sure it operates normally. HAWK 3I130TW supports onboard LPDDR5 16GB/32GB memory , onboard NVME and could expand, M12 I/O ,PoE and features comprehensive storage options including two 2.5” mobile rack Bays also make it the ideal for in-vehicle / Railway applications.
Features
- Intel® 13th Gen Raptor Lake-U, i7 / i5 / i3, Pentium CPU
- Intel® 12th Gen Alder Lake-U, i7 / i5 / i3, Celeron CPU
- Onboard LPDDR5, 16GB / 32GB
- Multiple Independent display:
1 x HDMI, 1 x DP, 1 x Type C DP ALT Mode - 5 x Intel 2.5 GbE LAN, 3 x USB 3.2, 1 x USB 2.0
- 1 x M.2 M Key, 2 x M.2 BKey, 1 x Nano SIM
- 2 x COM, 4DI / 4DO, TPM 2.0, SMBus, I2C
- ISO Wide Range DC-IN, CPC-Ignition on/off control
| MODEL | HAWK-3I130TW | |
|---|---|---|
| System Dimension(WxDxH) | 220W x 172.6D x 80H mm 220W x 176.6D x 80H mm (Mobile Rack-option) |
|
| Weight(Incl.M/B) | 3.6 kg | |
| Mounting | *System Mount *VESA Mount | |
| CPU | Intel® 13th Gen Raptor Lake-U, i7 / i5 / i3, Pentium CPU Intel® 12th Gen Alder Lake-U, i7 / i5 / i3, Celeron CPU |
|
| Chipset | Intel Raptor LakeU ; Alder Lake-U SoC | |
| Memory | Onboard LPDDR5, 16GB / 32GB | |
| Storage | OEM option-Onboard (256GB / 512 GB / 1TB) NVMe, Mobile Rack x 2 (option), M.2-SSD |
|
| Expansion slots | 1 x M.2 B key Type 3042 (PCIe x1 / USB 2.0) 1 x M.2 M key Type 3042 / 3080 (PCIe x 4), Support NVMe 1 x M.2 B key Type 3042 / 3052 (USB 3.2 Gen 1 x 1 / USB 2.0) 1 x Nano SIM |
|
| I/O ports | Network | 5 x Intel 2.5GbE I226-IT |
| USB | 3 x USB 3.2 Gen 1 x1, 1 x USB 2.0 1 x Type C USB 3.2 |
|
| Serial ports | 2 ISO RS232 / 422 / 485 | |
| Display | 1 x HDMI, 1 x DP, 1 x Type C DP ALT Mode |
|
| GPIO | 4 x DI / 4 x DO (option) | |
| HD Audio | Line-out / Mic-in | |
| Optional Modules & Accessory |
*SATA Kit *VESA Mounting Kit *System Mounting Kit |
|
| Power | DC input :
|
|
| Operating Temp. (100 % CPU usage) |
-40°C~ + 70°C (under specific environmental & CPU power consumption conditions) |
|
| Storage Temp. | -40°C~70°C | |
| Relative Humidity | 95% @ 40°C, non-condensing | |
| OS Support | Windows® 10 IOT ; Windows® 11 IOT Ubuntu 22.04 above, Fedora 36 above | |
