2I740CW
1 x HDMI® ; 1 x USB 3.2 Type C DP ALT ; 1 x LVDS, 2 x Intel 2.5Gb Ethernet,
6 x USB, 4 x COM, 2 x M.2, 1 x Nano SIM, 2 x MIPI-CSI, DI/O
Overview
LEX System ultra-compact SBC (108 x 102mm) – 2I740CW is powered by Intel® Atom™ x7000 (formerly Amston Lake) Series processors. The 2I740CW integrates 2 x 2.5GbE LAN ports, 6 x USB ports, 4 x COM ports, HDMI®, LVDS, 1 x USB 3.2 Type-C with DP Alt Mode, 2 x MIPI-CSI camera interfaces, and 2 x M.2, 1 x Nano SIM expansion slots, making it an ideal platform for high-performance graphics with built-in IoT capabilities, real-time processing, manageability, and security.
With its low power consumption, multiple 2.5GbE Ethernet ports, and wide range 9–36V DC input, the 2I740CW is an excellent choice for OpenVINO-based AI accelerator platforms and advanced Edge AI applications, including intelligent control, factory automation (Industry 4.0), IoT, and edge computing.
Features
- Intel® Amston Lake ATOM® x7000 series CPU
- 1 x DDR5 SODIMM, Max. 16GB
- Independent display: 1 x HDMI® ;
1 x USB 3.2 Type C DP ALT ; 1 x LVDS - 2 x Intel 2.5 GbE LAN, 3 x USB 3.2 (Type A),
1 x USB 3.2 (Type C) 2 x USB 2.0 - 4 x COM, 2 x M.2, 1 x Nano SIM, 2 x MIPI-CSI
- TPM 2.0, 4DI/4DO
| MODEL | 2I740CW |
|---|---|
| CPU | Intel® Amston Lake ATOM® x7000 series CPU |
| MB Chipset | Intel® Amston Lake SoC |
| Graphics | Intel® HD Graphics, Support DirectX 12.1 & OpenGL 4.6 |
| System Memory | 1 x DDR5 SODIMM, Max. 16GB |
| Storage | 1 x M.2 B Key Type 3042 / 2242 SATA-SSD 1 x M.2 B Key Type 2242 PCIe-SSD 1 x SATA |
| BIOS | Insyde UEFI 64BIOS |
| Display | 1 x HDMI® ; 1 x USB 3.2 Type C DP ALT ; 1 x LVDS |
| TPM | Hardware TPM 2.0 ; OEM Optional to Firmware TPM 2.0 |
| LAN | 2 x Intel 2.5 GbE I226 (external) |
| Expansion Interface | 1 x M.2 B Key Type2242/3042 (SATA / USB 3.2 / USB 2.0) 1 x M.2 B Key Type2242 (PCIe x2 / USB 2.0) 1 x Nano SIM |
| Expansion Module | CN064 : M.2 B key 2242 to M.2 E Key 2230, WiFi 6 + BT CN067 : M.2 B key 2242 to M.2 B Key 2252, 4G / 5G (3.7V by BOM Control) CN059 : USB to Line-out / Mic-in CC007 : USB to 4 port COM CIO116G : SMBus to 8DI + 8DO PW351 : 1 port PoE PSE PW352 : 2 port PoE PSE PW301 : 802.3AF / AT PD module PW205 : Wide Range power board (9~36V) with power Ignition on/off delay PW206 : 12V / 24V DC to DC Redundant Power Board PW022 : Wide Range power board (24V / 48V) |
| USB | 3 x USB 3.2 Gen 1 (Type A / external) ; 2 x USB 2.0 (internal) 1 x USB 3.2 Type C (Type C / external) |
| Serial IO | 4 x RS232 / 422 / 485 (internal) *COM1~COM4 Pin9 5V/12V (option) |
| Camera Interface | 2 x MIPI-CSI (internal) |
| SMBus / I2C | 1 x SMBus, 1 x I2C |
| GPIO | Hardware digital Input & Output, 4 x DI / 4 x DO |
| WDT | Hardware Watch Dog Timer, 0~255 sec programmable |
| Power Input | Wide Range +9~36V |
| Dimension | 2.5" Plus (108W x 102D mm) ; Weight: 100g |
| Operation Temperature | -20°C~70°C (100 % CPU Usage) |
| Operation Humidity | 5~95%, non-condensing |
| Chassis (OEM I/O Expansion by request) | Box PC: NET-II, Panel PC |
| OS Support | Windows® 10 IOT ; Windows® 11 IOT Ubuntu 22.04 above, Fedora 36 above |
